3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 41 mm x 50 m, 3 in Paper Core, 7 Rolls/Case
3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.
Special Price
$480.63
Regular Price
$565.45
| UPC | 00051128609446 |
|---|---|
| 3M ID | 7100040587 |
| Packaging | Case |
Sorry, We Are Out of Stock
- Get up to 15% OFF
- Exclusive Deals and Discounts
- Secure Shopping Experience
- Fast and Friendly Customer Support
3M™ EMI Shielding Tape 1183 has a deadsoft, copper foil backing with a pressure sensitive, electrically conductive, acrylic adhesive that ensures firm adherence. This tape has tin plating, which resists oxidation and facilitates soldering to the backing. The conductive particles in the adhesive offer low resistance between the substrate and the backing. This tape withstands a wide temperature range of 40 to 266 °F ( 40 to 130 °C). This flame retardant tape is designed for grounding and EMI shielding in equipment, components and shielded rooms. UL Listed and RoHS 2011/65/EU Compliant.
- Unique adhesive creates secure contact with the application surface
- Suitable for grounding and EMI shielding equipment, components and shielded rooms
- Flame-retardant
- Comes on a removable liner for easy die-cutting and handling
- Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
- Rated for 600V applications
- UL Listed and RoHS 2011/65/EU Compliant
| 3M ID | 7100040587 |
|---|---|
| Part number | 1183 41MM X 50M |
| Keywords | 3M, tin-plated copper foil tape, EMI shielding tape, flame-retardant tape, electrical conductivity tape, removable liner tape, 600V rated tape, UL Listed tape, RoHS compliant tape, grounding tape, EMI shielding equipment, die-cutting tape, automotive shielding tape, energy market tape, electrical equipment tape, power distribution tape, powertrain shielding tape, high-temperature range tape, acrylic adhesive tape, conductive tape, oxidation-resistant tape, solderable tape, deadsoft copper foil tape, pressure-sensitive adhesive tape, EMI shielding components, shielded rooms tape, tape for electronic applications. |
| Global Product Hierarchy | Tapes > Foil Tapes > Copper Tapes |
| Backing (Carrier) Material | Tin Plated Copper Foil, Flat |
| Backing (Carrier) Thickness (Imperial) | 1.4 mil |
| Backing (Carrier) Thickness (Metric) | 0.035 mm |
| Color Family | Gray |
| Product Color | Tin |
| Product Type | simple |
| Quantity | 0 |
| Country of Origin | Taiwan |
| SAP Shelf Life In Days | 1825 |
| Base - Billing Unit | ROL |
| Base - Metric Gross Weight | 1.142 KG |
| Base - Metric Height Dimension | 104.14 MM |
| Base - Metric Length Dimension | 40.996 MM |
| Base - Metric Width Dimension | 104.14 MM |
| Base - Item Quantity | 1 |
| Base - Unit | ROL |
| Unit of Use - Billing Unit | ROL |
| Unit of Use - Customary Cubic Dimension | 27.155566122155868 ci |
| Unit of Use - Customary Gross Weight | 2.517679034151302 lbs |
| Unit of Use - Customary Net Weight | 2.517679034151302 lbs |
| Unit of Use - Customary Height Dimension | 4.1 in |
| Unit of Use - Customary Length Dimension | 1.614015748031496 in |
| Unit of Use - Customary Width Dimension | 4.1 in |
| Unit of Use - Metric Cubic Dimension | 0.445 CDM |
| Unit of Use - Metric Net Weight | 1.142 KG |
| Unit of Use - Metric Height Dimension | 104.14 MM |
| Unit of Use - Metric Length Dimension | 40.996 MM |
| Unit of Use - Metric Width Dimension | 104.14 MM |
| Unit of Use - Item Quantity | 1 |
| Unit of Use - Total Unit Quantity | 1 |
| Unit of Use - Previous Packaging Level Quantity | 1 |
| Unit of Use - Item Unit | RLS |
| Unit of Use - Unit | ROL |
| Shipper - Billing Unit | ROL |
| Shipper - Customary Cubic Dimension | 1027.1454361806361 ci |
| Shipper - Customary Gross Weight | 18.496783797311227 lbs |
| Shipper - Customary Net Weight | 17.623753239059113 lbs |
| Shipper - Customary Height Dimension | 14.606299212598426 in |
| Shipper - Customary Length Dimension | 8.385826771653543 in |
| Shipper - Customary Width Dimension | 8.385826771653543 in |
| Shipper - Metric Cubic Dimension | 16831.898 CCM |
| Shipper - Metric Weight | 8.39 KG |
| Shipper - Metric Net Weight | 7.994 KG |
| Shipper - Metric Height Dimension | 37.1 CM |
| Shipper - Metric Length Dimension | 21.3 CM |
| Shipper - Metric Width Dimension | 21.3 CM |
| Shipper - Item Quantity | 7 |
| Shipper - Total Unit Quantity | 7 |
| Shipper - Previous Packaging Level Quantity | 7 |
| Shipper - Previous Packaging Level Unit | RLS |
| Shipper - Item Unit | RLS |
| Shipper - Unit | CS |
| Pallet - Billing Unit | ROL |
| Pallet - Customary Cubic Dimension | 98778.89047116677 ci |
| Pallet - Customary Gross Weight | 1421.9815910924603 lbs |
| Pallet - Customary Net Weight | 1321.7814929294336 lbs |
| Pallet - Customary Height Dimension | 48.818897637795274 in |
| Pallet - Customary Length Dimension | 48.031496062992126 in |
| Pallet - Customary Width Dimension | 42.125984251968504 in |
| Pallet - Metric Cubic Dimension | 1618.696 CDM |
| Pallet - Metric Net Weight | 599.55 KG |
| Pallet - Metric Height Dimension | 124.0 CM |
| Pallet - Metric Length Dimension | 122.0 CM |
| Pallet - Metric Width Dimension | 107.0 CM |
| Pallet - Item Quantity | 525 |
| Pallet - Total Unit Quantity | 525 |
| Pallet - Previous Packaging Level Quantity | 75 |
| Pallet - Previous Packaging Level Unit | BOX |
| Pallet - Item Unit | RLS |
| Pallet - Unit | PAL |
| Pallet - Pallet Layer Quantity | 3 |
| Pallet - Shipping Container Per Layer Quantity | 25 |
