3M™ Embossed Tin-Plated Copper Foil EMI Shielding Tape 1345, 3 in x 60 yd, 3 in Paper Core, 4 Rolls/Case
3M™ Embossed Tin Plated Copper EMI Shielding Tape 1345 is an EMI shielding tape with an acrylic adhesive. This flame retardant tape is designed for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.
Special Price
$890.81
Regular Price
$1,048.01
| UPC | 00051138516994 |
|---|---|
| 3M ID | 7010395804 |
| Packaging | Case |
Sorry, We Are Out of Stock
- Get up to 15% OFF
- Exclusive Deals and Discounts
- Secure Shopping Experience
- Fast and Friendly Customer Support
3M™ EMI Shielding Tape 1345 has an embossed, deadsoft, copper foil backing with a pressure sensitive, acrylic adhesive that ensures firm adherence. The tin plated coating on both sides of the tape's foil backing offers outstanding solderability and is resistant to oxidation and corrosion. The copper foil backing of the tape offers excellent resistance against oxidation and discoloration. Contact between the backing and the application substrate is established when the embossed backing edges cut through the adhesive layer. The tape withstands a wide temperature range of 40 to 266 °F ( 40 to 130 °C). This flame retardant tape is designed for grounding and EMI shielding in equipment, components and shielded rooms. UL Listed and RoHS 2011/65/EU Compliant.
- Embossed, copper foil backing resists discoloration and oxidation
- Offers stable contact resistance and good shielding effectiveness
- Embossed backing cuts through the layer of adhesive for establishing contact between the backing and the application substrate
- Flame-retardant and suitable for grounding and EMI shielding in equipment, components and shielded rooms
- Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
- Offers outstanding solderability with tin-plated coating
- Rated for 600V applications
- UL Listed and RoHS 2011/65/EU Compliant
| 3M ID | 7010395804 |
|---|---|
| Part number | 1345 3"X60YD |
| Global Product Hierarchy | Tapes > Foil Tapes > Copper Tapes |
| Backing (Carrier) Material | Tin Plate Copper Foil, Embossed |
| Backing (Carrier) Thickness (Imperial) | 1.4 mil |
| Backing (Carrier) Thickness (Metric) | 0.035 mm |
| Product Type | simple |
| Quantity | 0 |
| Country of Origin | Taiwan |
| SAP Shelf Life In Days | 1825 |
| Base - Billing Unit | ROL |
| Base - Metric Gross Weight | 2.062 KG |
| Base - Metric Height Dimension | 151.46 MM |
| Base - Metric Length Dimension | 76.2 MM |
| Base - Metric Width Dimension | 151.46 MM |
| Base - Item Quantity | 1 |
| Base - Unit | ROL |
| Unit of Use - Billing Unit | ROL |
| Unit of Use - Customary Cubic Dimension | 106.67182357986763 ci |
| Unit of Use - Customary Gross Weight | 4.545931846252175 lbs |
| Unit of Use - Customary Net Weight | 4.545931846252175 lbs |
| Unit of Use - Customary Height Dimension | 5.962992125984252 in |
| Unit of Use - Customary Length Dimension | 3.0 in |
| Unit of Use - Customary Width Dimension | 5.962992125984252 in |
| Unit of Use - Metric Cubic Dimension | 1748.038 CCM |
| Unit of Use - Metric Net Weight | 2.062 KG |
| Unit of Use - Metric Height Dimension | 151.46 MM |
| Unit of Use - Metric Length Dimension | 76.2 MM |
| Unit of Use - Metric Width Dimension | 151.46 MM |
| Unit of Use - Item Quantity | 1 |
| Unit of Use - Total Unit Quantity | 1 |
| Unit of Use - Previous Packaging Level Quantity | 1 |
| Unit of Use - Item Unit | RLS |
| Unit of Use - Unit | ROL |
| Shipper - Billing Unit | ROL |
| Shipper - Customary Cubic Dimension | 969.8906405686827 ci |
| Shipper - Customary Gross Weight | 18.362301817378455 lbs |
| Shipper - Customary Net Weight | 18.1837273850087 lbs |
| Shipper - Customary Height Dimension | 14.25 in |
| Shipper - Customary Length Dimension | 8.25 in |
| Shipper - Customary Width Dimension | 8.25 in |
| Shipper - Metric Cubic Dimension | 15893.66 CCM |
| Shipper - Metric Weight | 8.329 KG |
| Shipper - Metric Net Weight | 8.248 KG |
| Shipper - Metric Height Dimension | 36.195 CM |
| Shipper - Metric Length Dimension | 20.955 CM |
| Shipper - Metric Width Dimension | 20.955 CM |
| Shipper - Item Quantity | 4 |
| Shipper - Total Unit Quantity | 4 |
| Shipper - Previous Packaging Level Quantity | 4 |
| Shipper - Previous Packaging Level Unit | RLS |
| Shipper - Item Unit | RLS |
| Shipper - Unit | CS |
| Pallet - Billing Unit | ROL |
| Pallet - Customary Cubic Dimension | 96264.0043390323 ci |
| Pallet - Customary Gross Weight | 1411.9990598607292 lbs |
| Pallet - Customary Net Weight | 1363.7795538756527 lbs |
| Pallet - Customary Height Dimension | 47.75 in |
| Pallet - Customary Length Dimension | 48.0 in |
| Pallet - Customary Width Dimension | 42.0 in |
| Pallet - Metric Cubic Dimension | 1577484.4 CCM |
| Pallet - Metric Net Weight | 618.6 KG |
| Pallet - Metric Height Dimension | 121.285 CM |
| Pallet - Metric Length Dimension | 121.92 CM |
| Pallet - Metric Width Dimension | 106.68 CM |
| Pallet - Item Quantity | 300 |
| Pallet - Total Unit Quantity | 300 |
| Pallet - Previous Packaging Level Quantity | 75 |
| Pallet - Previous Packaging Level Unit | BOX |
| Pallet - Item Unit | RLS |
| Pallet - Unit | PAL |
| Pallet - Pallet Layer Quantity | 3 |
| Pallet - Shipping Container Per Layer Quantity | 25 |
