3M™ Double Coated Tape 9420, Red, 1 in x 36 yd, 4 mil, 48 Roll/Case
| UPC | 00021200160554 |
|---|---|
| 3M ID | 7010372140 |
| Packaging | Case |
- Get up to 15% OFF
- Exclusive Deals and Discounts
- Secure Shopping Experience
- Fast and Friendly Customer Support
Thick and Versatile
3M™ Double Coated Tape 9420 is a 6.5 mil double-sided tape utilizing a 0.5 mil hand-tearable polyester film carrier lined on both sides with acrylic adhesive. It has a high coat weight and adheres well to low surface energy substrates. This product provides excellent UV resistance. Once bonded, this tape provides excellent peel and shear strength – making it ideal for rigorous splicing applications and bonding plastics to metals. 3M™ Double Coated Tape 9420 is mounted on a 55# glassine backing to enable ease of deployment. Notably, the tape's red color makes it visible in splicing applications.
Recommended Applications
High speed splicing applications Applications where adhesion to low surface energy substrates is needed Bonding decorative trim, plastics and metal profile extrusions Attachment to irregular surfaces Seaming of vinyl banners
Universal all-purpose bonding applications common to double coated tapes
Aggressive Adhesion
3M™ Double Coated Tape 9420 is coated on both sides with an aggressive, pressure sensitive acrylic adhesive. This bonding agent provides an ultra-high peel acrylic adhesive system that bonds well to most substrates, including low surface energy plastics. It provides superior bonding and conformability to irregular as well as flat surfaces.
What is Double Coated Tape?
In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in web processing, construction, fabrication, arts and hobby industries, among others.
- Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications
- High tack for flying splices
- Bonds well to most substrates, including low surface energy films
- Excellent UV resistance to withstand a variety of conditions
- Conformable to bond to irregular surfaces
- Double sided adhesion increases dimensional stability for easy handling
- Red option available for visible splicing applications
| 3M ID | 7010372140 |
|---|---|
| Keywords | 3M, double coated tape, 3M Double Coated Tape 9420, polyester film tape, aggressive adhesive, pressure sensitive adhesive, glassine release liner, hand-tearable polyester film, superior bonding, irregular surfaces, flat surfaces, high peel strength, shear strength, rigorous splicing, high tack, flying splices, low surface energy films, UV resistance, dimensional stability, visible splicing, 6.5 mil tape, acrylic adhesive, bonding plastics to metals, high speed splicing, decorative trim bonding, plastics and metal bonding, vinyl banner seaming, all-purpose bonding, aggressive adhesion, general double coated tape, manual tape dispenser, automatic tape dispenser, web processing, construction, fabrication, automotive tape, commercial solutions, electronics tape, manufacturing tape, transportation tape, appliance bonding, |
| Global Product Hierarchy | Tapes > Splicing & Tabbing Tapes |
| Application | Zero-Speed and General Splicing |
| Backing (Carrier) Material | Polyester |
| Backing (Carrier) Thickness (Imperial) | 0.095 mil |
| Backing (Carrier) Thickness (Metric) | 0.03 mm |
| Color Family | Red |
| Face Side Adhesive Thickness (Imperial) | 1.5 mil |
| Number of Adhesive Sides | Double-sided |
| Product Color | Red |
| Product Number | 9420 |
| Product Type | simple |
| Quantity | 0 |
| Tape Type | Double Coated |
| Trademark 1 | 3M™ |
| Country of Origin | United States |
| SAP Shelf Life In Days | 730 |
| Base - Billing Unit | ROL |
| Base - Metric Gross Weight | 194.591 G |
| Base - Metric Height Dimension | 25.4 MM |
| Base - Metric Length Dimension | 122.682 MM |
| Base - Metric Width Dimension | 122.68 MM |
| Base - Item Quantity | 1 |
| Base - Unit | ROL |
| Unit of Use - Billing Unit | ROL |
| Unit of Use - Customary Cubic Dimension | 23.328523034998828 ci |
| Unit of Use - Customary Gross Weight | 0.42899972060817515 lbs |
| Unit of Use - Customary Net Weight | 0.4289754697593348 lbs |
| Unit of Use - Customary Height Dimension | 1.0 in |
| Unit of Use - Customary Length Dimension | 4.83 in |
| Unit of Use - Customary Width Dimension | 4.82992125984252 in |
| Unit of Use - Metric Cubic Dimension | 382.286 CCM |
| Unit of Use - Metric Net Weight | 194.58 G |
| Unit of Use - Metric Height Dimension | 25.4 MM |
| Unit of Use - Metric Length Dimension | 122.682 MM |
| Unit of Use - Metric Width Dimension | 122.68 MM |
| Unit of Use - Item Quantity | 1 |
| Unit of Use - Total Unit Quantity | 1 |
| Unit of Use - Previous Packaging Level Quantity | 1 |
| Unit of Use - Item Unit | RLS |
| Unit of Use - Unit | ROL |
| Shipper - Billing Unit | ROL |
| Shipper - Customary Cubic Dimension | 1784.7492387898162 ci |
| Shipper - Customary Gross Weight | 21.799308484840694 lbs |
| Shipper - Customary Net Weight | 20.591175288067568 lbs |
| Shipper - Customary Height Dimension | 14.75 in |
| Shipper - Customary Length Dimension | 11.0 in |
| Shipper - Customary Width Dimension | 11.0 in |
| Shipper - Metric Cubic Dimension | 29246.8 CCM |
| Shipper - Metric Weight | 9.888 KG |
| Shipper - Metric Net Weight | 9.34 KG |
| Shipper - Metric Height Dimension | 37.465 CM |
| Shipper - Metric Length Dimension | 27.94 CM |
| Shipper - Metric Width Dimension | 27.94 CM |
| Shipper - Item Quantity | 48 |
| Shipper - Total Unit Quantity | 48 |
| Shipper - Previous Packaging Level Quantity | 48 |
| Shipper - Previous Packaging Level Unit | RLS |
| Shipper - Item Unit | RLS |
| Shipper - Unit | CS |
| Pallet - Billing Unit | ROL |
| Pallet - Customary Cubic Dimension | 99102.56040984523 ci |
| Pallet - Customary Gross Weight | 820.0093841966521 lbs |
| Pallet - Customary Net Weight | 741.2690826347012 lbs |
| Pallet - Customary Height Dimension | 49.21259842519685 in |
| Pallet - Customary Length Dimension | 47.99212598425197 in |
| Pallet - Customary Width Dimension | 41.968503937007874 in |
| Pallet - Metric Cubic Dimension | 1.624 M3 |
| Pallet - Metric Net Weight | 336.234 KG |
| Pallet - Metric Height Dimension | 1.25 M |
| Pallet - Metric Length Dimension | 1.219 M |
| Pallet - Metric Width Dimension | 1.066 M |
| Pallet - Item Quantity | 1728 |
| Pallet - Total Unit Quantity | 1728 |
| Pallet - Previous Packaging Level Quantity | 36 |
| Pallet - Previous Packaging Level Unit | BOX |
| Pallet - Item Unit | RLS |
| Pallet - Unit | PAL |
| Pallet - Pallet Layer Quantity | 3 |
| Pallet - Shipping Container Per Layer Quantity | 12 |
